| APPLICATION | Water wells, Piling, Solar |
| DRILLING METHOD | DTH / Rotary |
| DRILLING CAPACITY | Water well: 200 m @ 165 mm (6 ½”) diameter Piling: 75 m @ 1200 mm (47.2”) diameter direct mud circulation method |
| FORMATION | Soft / Hard |
| PRIME MOVER | The rig hydraulic system is powered by a suitable deck engine |
| ROTARY HEAD TORQUE | 3000 Nm |
| ROTARY HEAD SPEED | 0 - 150 rpm |
| PULL UP FORCE | 7900 kgf |
| PULL DOWN FORCE | 5400 kgf |
| PULL UP SPEED | 49 m/min |
| PULL DOWN SPEED | 71 m/min |
| JACKS | Four Box type hydraulic jacks |
| COMPRESSOR | 600 cfm - 200 psi 1100 cfm - 300 psi |
| WATER PUMP | Maximum Flow: 50 lpm Working Pressure: 350 psi |
| OPTIONAL ATTACHMENTS | Welding machine Auxiliary winch : 1 ton Single Rod Changer |
